Name: DEORE XT WH-M8120 27.5"
Brand: Shimano
SKU: EWHM8120LFEBD7X
Price: 210 USD
Availability: InStock

Performance You Can Trust

$210.00

Low stock | SKU -
Inventory on the way

Wheel

Front

Rear

Pair

Freehub Body

N/A

MICRO SPLINE

Freehub & Cassette Compatibility Chart

Product Locator by Locally

When trail conditions demand reliability, DEORE XT wheels deliver. An offset aluminum tubeless rim and smooth-rolling CENTER LOCK hubs provide stable handling and consistent performance, with MICRO SPLINE compatibility and a 12 mm E-THRU axle.

⚠️ WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Durable Alloy Tubeless Rim: Offset aluminum rim promotes balanced spoke tension for stable handling and reliable trail performance

28H Double-Butted Spokes: 2.0–1.8–2.0 mm J-bend spokes deliver strength, durability, and consistent wheel stiffness

Smooth, Reliable Hub Performance: CENTER LOCK hubs with labyrinth seals provide smooth rotation and long-term reliability

MICRO SPLINE Freehub: Smaller spline diameter supports modern wide-range drivetrains, including 10T top gears

Trail-Ready Standards: 27.5” wheels with 148×12 rear E-THRU axle and ZERO dish design support balanced performance across trail wheel sizes.

Ground (non-expedited) orders will leave our distribution centers within 72 hours.
Expedited orders (Overnight and 2-day) will leave our distribution center within 24 hours.

We ship Monday - Friday and are closed weekends and holidays. We cannot guarantee carrier travel time. Delivery time is only an estimate and is based on standard conditions and carrier service estimates.

All SHIMANO wheels are subject to a $20 return shipping fee. This fee will be deducted from your refund or applied to exchanges. Original shipping charges are non-refundable.

Flat Rate Ground Shipping $5 $20 Return Fee Up to 2 Year Warranty

[{"id":53265587077483,"title":"Front \/ N\/A","option1":"Front","option2":"N\/A","option3":null,"sku":"EWHM8120LFEBD7X","requires_shipping":true,"taxable":true,"featured_image":{"id":56228088545643,"product_id":15015091929451,"position":1,"created_at":"2026-06-13T00:34:33-07:00","updated_at":"2026-06-13T00:34:34-07:00","alt":"#wheel_front|#wheel_front","width":1500,"height":1500,"src":"\/\/ride.shimano.com\/cdn\/shop\/files\/hcy7qki3gsnpireulugq.jpg?v=1781336074","variant_ids":[53265587077483]},"available":true,"name":"DEORE XT WH-M8120 27.5\" - Front \/ N\/A","public_title":"Front \/ N\/A","options":["Front","N\/A"],"price":21000,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"192790449494","featured_media":{"alt":"#wheel_front|#wheel_front","id":48096999440747,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/ride.shimano.com\/cdn\/shop\/files\/hcy7qki3gsnpireulugq.jpg?v=1781336074"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":53372952183147,"title":"Rear \/ MICRO SPLINE","option1":"Rear","option2":"MICRO SPLINE","option3":null,"sku":"EWHM8120LREBD7","requires_shipping":true,"taxable":true,"featured_image":{"id":56228088676715,"product_id":15015091929451,"position":5,"created_at":"2026-06-13T00:34:33-07:00","updated_at":"2026-06-13T00:34:34-07:00","alt":"#wheel_rear|#wheel_rear","width":1000,"height":1000,"src":"\/\/ride.shimano.com\/cdn\/shop\/files\/ilojbuendpbmvlceaxxx.jpg?v=1781336074","variant_ids":[53372952183147]},"available":false,"name":"DEORE XT WH-M8120 27.5\" - Rear \/ MICRO SPLINE","public_title":"Rear \/ MICRO SPLINE","options":["Rear","MICRO SPLINE"],"price":21000,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"192790449579","featured_media":{"alt":"#wheel_rear|#wheel_rear","id":48096999571819,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/ride.shimano.com\/cdn\/shop\/files\/ilojbuendpbmvlceaxxx.jpg?v=1781336074"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":53265587110251,"title":"Pair \/ MICRO SPLINE","option1":"Pair","option2":"MICRO SPLINE","option3":null,"sku":"EWHM8120LFEREBD7X","requires_shipping":true,"taxable":true,"featured_image":{"id":56228088578411,"product_id":15015091929451,"position":2,"created_at":"2026-06-13T00:34:33-07:00","updated_at":"2026-06-13T00:34:34-07:00","alt":"#wheel_pair|#wheel_pair","width":1500,"height":1500,"src":"\/\/ride.shimano.com\/cdn\/shop\/files\/ca1ykpuit2kvsamduute.jpg?v=1781336074","variant_ids":[53265587110251]},"available":true,"name":"DEORE XT WH-M8120 27.5\" - Pair \/ MICRO SPLINE","public_title":"Pair \/ MICRO SPLINE","options":["Pair","MICRO SPLINE"],"price":46500,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"192790449548","featured_media":{"alt":"#wheel_pair|#wheel_pair","id":48096999473515,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/ride.shimano.com\/cdn\/shop\/files\/ca1ykpuit2kvsamduute.jpg?v=1781336074"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

{"id":53265587077483,"title":"Front \/ N\/A","option1":"Front","option2":"N\/A","option3":null,"sku":"EWHM8120LFEBD7X","requires_shipping":true,"taxable":true,"featured_image":{"id":56228088545643,"product_id":15015091929451,"position":1,"created_at":"2026-06-13T00:34:33-07:00","updated_at":"2026-06-13T00:34:34-07:00","alt":"#wheel_front|#wheel_front","width":1500,"height":1500,"src":"\/\/ride.shimano.com\/cdn\/shop\/files\/hcy7qki3gsnpireulugq.jpg?v=1781336074","variant_ids":[53265587077483]},"available":true,"name":"DEORE XT WH-M8120 27.5\" - Front \/ N\/A","public_title":"Front \/ N\/A","options":["Front","N\/A"],"price":21000,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"192790449494","featured_media":{"alt":"#wheel_front|#wheel_front","id":48096999440747,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/ride.shimano.com\/cdn\/shop\/files\/hcy7qki3gsnpireulugq.jpg?v=1781336074"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}

DEORE XT

Proven for Trail Riding

Proven durability, consistent control, and practical serviceability, DEORE XT delivers for trail riding.

Controlled Trail Handling

The offset aluminum tubeless rim and zero-dish construction improve spoke balance, supporting stable tracking and confident cornering at speed. Designed for trail riding, the rim delivers dependable handling through changing terrain and trail conditions.

Smooth Reliable Hub

DEORE XT CENTER LOCK hubs use proven labyrinth seals to maintain smooth rolling while keeping dirt and moisture out. Paired with MICRO SPLINE compatibility and a 12 mm E-THRU axle, they deliver reliable engagement with a simple trail setup.

Specifications

Rim Material	Aluminum
Rim Construction	Hooked
Spoke Material	Stainless steel
Spoke Type	J-bend
Spokes	28
Front Weight	875 g
Front Weight 27.5	875 g
Rear Weight	1016 g
Rear Weight 27.5	1016 g
Wheel Size	27.5"
Tubeless Ready	YES
Front Axle	15 mm E-THRU
Rear Axle	12 mm E-THRU
Freehub	MICRO SPLINE
Bearings	Cone
External Width	34.7 mm
Internal Width	30 mm
Rim Height	19.8 mm
Hub Spacing O.L.D. Front	110mm
Hub Spacing O.L.D. Rear	148mm
Brake Type	CENTER LOCK Disc Brake
Hub Seal	Labyrinth+Contact
Offset Rim	X
Tire Type	Tubeless Ready

❮ ❯
